首页 > 供应产品 > 缆普LAPP 电缆和电线 单芯线 H07Z-K 90°C 1X6 GY
缆普LAPP 电缆和电线 单芯线 H07Z-K 90°C 1X6 GY
H07Z-K 90°C 1X6 GY 单芯线; 1X6; 灰色; 卷; 5.5 mm; U0/U: 450 / 750 V; 无卤素混合物; HAR-certified; 固定敷设
型号名称: 缆普LAPP 电缆和电线 单芯线 H07Z-K 90°C 1X6 GY
浏览次数: 21
产品品牌: 缆普LAPP
产品标签: 缆普 LAPP 电缆和电线 单芯线 4726064
产品单价: 面议
最小起订量:
供货总量: 电询
发货期限: 自买家付款之日起 3 天内发货
有效期至: 2023-12-19
最后更新: 2022-12-19 14:34

详细信息

优势

  • 根据统一欧洲规格 H07Z-K 制造,带 ◁HAR▷ 安全和质量检测标志(不适用于:透明、绿色(单色)、黄色(单色)、所有双色(除了绿黄和黄绿之外))。

  • ◁HAR▷ 电缆在欧洲得到广泛接受和使用。

  • 无卤芯线绝缘混合物以及在火灾中出现很少的烟雾和很少的腐蚀性气体,有利于在公共区域中使用。

  • 根据欧盟指令305/2011(BauPVO/CPR)对火灾行为进行分类,物料选型详见www.lappkabel.de/CPR。

  • 设计紧凑,易于加工。

  • 可提供不同芯线绝缘层颜色的款型。

  • 可提供卷装、盘装或一次性大包装箱的款型。根据颜色和横截面,可使用大纸板箱,通常导线横截面仅为6 mm²。

应用

  • 在遵守特殊消防要求的情况下,用于机器内部电路的布线。

  • 适用于控制柜内的布线。

  • 用于照明装置的布线。

  • 用于固定和保护安装在石膏上或下面的电气安装管道中。

  • 可在电缆桥架上用于等电位连接的开放式敷设。

  • 可用于干燥的房间。

  • 适用于40℃至+90℃的工作温度。

技术特性

基本信息

产品类型

单芯线

重量

0.065 kg

铜号

57.600 kg

铜重 (lb)

387.000 lb

产品设计

电缆尺寸

1X6

认证标准

EAC certified


EAC 认证编号

ЕАЭС RU С-DE.АЮ64.В.00091/19, ЕАЭС RU С-DE.АЮ64.В.00110/20

产品系列列表

所有物料号来自 H07Z-K 90°C

物料编号导体额定横截面 (mm2)单芯线颜色单芯线包装类型最大芯线直径铜号重量
47260011.5 mm²绿色-黄色3.5 mm14.400 kg0.020 kg
4726001K1.5 mm²绿色-黄色大纸箱3.5 mm14.400 kg0.020 kg
4726001S1.5 mm²绿色-黄色盘装3.5 mm14.400 kg0.020 kg
47260022.5 mm²绿色-黄色4.3 mm24.000 kg0.032 kg
4726002K2.5 mm²绿色-黄色大纸箱4.3 mm24.000 kg0.030 kg
4726002S2.5 mm²绿色-黄色盘装4.3 mm24.000 kg0.032 kg
47260034 mm²绿色-黄色4.9 mm38.400 kg0.045 kg
4726003K4 mm²绿色-黄色大纸箱4.9 mm38.400 kg0.045 kg
47260046 mm²绿色-黄色5.5 mm57.600 kg0.065 kg
4726004K6 mm²绿色-黄色大纸箱5.5 mm57.600 kg0.065 kg
472600510 mm²绿色-黄色7.1 mm96.000 kg0.110 kg
472600616 mm²绿色-黄色8.4 mm153.600 kg0.170 kg
472600725 mm²绿色-黄色10.6 mm240.000 kg0.290 kg
472600835 mm²绿色-黄色12.1 mm336.000 kg0.400 kg
472600950 mm²绿色-黄色14.4 mm480.000 kg0.550 kg
47260111.5 mm²黑色3.5 mm14.400 kg0.020 kg
4726011K1.5 mm²黑色大纸箱3.5 mm14.400 kg0.020 kg
4726011S1.5 mm²黑色盘装3.5 mm14.400 kg0.020 kg
47260122.5 mm²黑色4.3 mm24.000 kg0.032 kg
4726012K2.5 mm²黑色大纸箱4.3 mm24.000 kg0.030 kg
4726012S2.5 mm²黑色盘装4.3 mm24.000 kg0.032 kg
47260134 mm²黑色4.9 mm38.400 kg0.045 kg
4726013K4 mm²黑色大纸箱4.9 mm38.400 kg0.045 kg
47260146 mm²黑色5.5 mm57.600 kg0.065 kg
4726014K6 mm²黑色大纸箱5.5 mm57.600 kg0.065 kg
472601510 mm²黑色7.1 mm96.000 kg0.110 kg
472601616 mm²黑色8.4 mm153.600 kg0.170 kg
472601725 mm²黑色10.6 mm240.000 kg0.243 kg
472601835 mm²黑色12.1 mm336.000 kg0.380 kg
472601950 mm²黑色14.4 mm480.000 kg0.530 kg
47260211.5 mm²蓝色3.5 mm14.400 kg0.020 kg
4726021K1.5 mm²蓝色大纸箱3.5 mm14.400 kg0.020 kg
4726021S1.5 mm²蓝色盘装3.5 mm14.400 kg0.020 kg
47260222.5 mm²蓝色4.3 mm24.000 kg0.032 kg
4726022K2.5 mm²蓝色大纸箱4.3 mm24.000 kg0.030 kg
4726022S2.5 mm²蓝色盘装4.3 mm24.000 kg0.032 kg
47260234 mm²蓝色4.9 mm38.400 kg0.045 kg
4726023K4 mm²蓝色大纸箱4.9 mm38.400 kg0.045 kg
47260246 mm²蓝色5.5 mm57.600 kg0.065 kg
4726024K6 mm²蓝色大纸箱5.5 mm57.600 kg0.065 kg
472602510 mm²蓝色7.1 mm96.000 kg0.110 kg
472602616 mm²蓝色8.4 mm153.600 kg0.170 kg
472602725 mm²蓝色10.6 mm240.000 kg0.290 kg
472602835 mm²蓝色12.1 mm336.000 kg0.400 kg
472602950 mm²蓝色14.4 mm480.000 kg0.550 kg
47260311.5 mm²褐色3.5 mm14.400 kg0.020 kg
4726031K1.5 mm²褐色大纸箱3.5 mm14.400 kg0.020 kg
4726031S1.5 mm²褐色盘装3.5 mm14.400 kg0.020 kg
47260322.5 mm²褐色4.3 mm24.000 kg0.032 kg
4726032K2.5 mm²褐色大纸箱4.3 mm24.000 kg0.030 kg
4726032S2.5 mm²褐色盘装4.3 mm24.000 kg0.032 kg
47260334 mm²褐色4.9 mm38.400 kg0.045 kg
4726033K4 mm²褐色大纸箱4.9 mm38.400 kg0.045 kg
47260346 mm²褐色5.5 mm57.600 kg0.065 kg
4726034K6 mm²褐色大纸箱5.5 mm57.600 kg0.065 kg
472603510 mm²褐色7.1 mm96.000 kg0.110 kg
472603616 mm²褐色8.4 mm153.600 kg0.170 kg
472603725 mm²褐色10.6 mm240.000 kg0.290 kg
472603835 mm²褐色12.1 mm336.000 kg0.400 kg
472603950 mm²褐色14.4 mm480.000 kg0.550 kg
47260411.5 mm²红色3.5 mm14.400 kg0.020 kg
4726041K1.5 mm²红色大纸箱3.5 mm14.400 kg0.020 kg
4726041S1.5 mm²红色盘装3.5 mm14.400 kg0.020 kg
47260422.5 mm²红色4.3 mm24.000 kg0.030 kg
4726042K2.5 mm²红色大纸箱4.3 mm24.000 kg0.030 kg
4726042S2.5 mm²红色盘装4.3 mm24.000 kg0.032 kg
47260434 mm²红色4.9 mm38.400 kg0.045 kg
4726043K4 mm²红色大纸箱4.9 mm38.400 kg0.045 kg
47260446 mm²红色5.5 mm57.600 kg0.065 kg
4726044K6 mm²红色大纸箱5.5 mm57.600 kg0.065 kg
472604510 mm²红色7.1 mm96.000 kg0.110 kg
472604616 mm²红色8.4 mm153.600 kg0.170 kg
472604725 mm²红色10.6 mm240.000 kg0.290 kg
472604835 mm²红色12.1 mm336.000 kg0.400 kg
472604950 mm²红色14.4 mm480.000 kg0.550 kg
47260511.5 mm²白色3.5 mm14.400 kg0.020 kg
4726051K1.5 mm²白色大纸箱3.5 mm14.400 kg0.020 kg
4726051S1.5 mm²白色盘装3.5 mm14.400 kg0.020 kg
47260522.5 mm²白色4.3 mm24.000 kg0.032 kg
4726052K2.5 mm²白色大纸箱4.3 mm24.000 kg0.032 kg
4726052S2.5 mm²白色盘装4.3 mm24.000 kg0.032 kg
47260534 mm²白色4.9 mm38.400 kg0.045 kg
4726053K4 mm²白色大纸箱4.9 mm38.400 kg0.045 kg
47260546 mm²白色5.5 mm57.600 kg0.065 kg
4726054K6 mm²白色大纸箱5.5 mm57.600 kg0.290 kg
472605510 mm²白色7.1 mm96.000 kg0.110 kg
472605616 mm²白色8.4 mm153.600 kg0.170 kg
472605725 mm²白色10.6 mm240.000 kg0.290 kg
472605835 mm²白色12.1 mm336.000 kg0.400 kg
472605950 mm²白色14.4 mm480.000 kg0.550 kg
47260611.5 mm²灰色3.5 mm14.400 kg0.020 kg
4726061K1.5 mm²灰色大纸箱3.5 mm14.400 kg0.020 kg
4726061S1.5 mm²灰色盘装3.5 mm14.400 kg0.020 kg
47260622.5 mm²灰色4.3 mm24.000 kg0.032 kg
4726062K2.5 mm²灰色大纸箱4.3 mm24.000 kg0.030 kg
4726062S2.5 mm²灰色盘装4.3 mm24.000 kg0.032 kg
47260634 mm²灰色4.9 mm38.400 kg0.045 kg
4726063K4 mm²灰色大纸箱4.9 mm38.400 kg0.045 kg
47260646 mm²灰色5.5 mm57.600 kg0.065 kg
4726064K6 mm²灰色大纸箱5.5 mm57.600 kg0.065 kg
472606510 mm²灰色7.1 mm96.000 kg0.110 kg
472606616 mm²灰色8.4 mm153.600 kg0.170 kg
472606725 mm²灰色10.6 mm240.000 kg0.290 kg
472606835 mm²灰色12.1 mm336.000 kg0.400 kg
472606950 mm²灰色14.4 mm480.000 kg0.550 kg
47260711.5 mm²紫色3.5 mm14.400 kg0.020 kg
4726071K1.5 mm²紫色大纸箱3.5 mm14.400 kg0.020 kg
4726071S1.5 mm²紫色盘装3.5 mm14.400 kg0.020 kg
47260722.5 mm²紫色4.3 mm24.000 kg0.030 kg
4726072K2.5 mm²紫色大纸箱4.3 mm24.000 kg0.030 kg
4726072S2.5 mm²紫色盘装4.3 mm24.000 kg0.032 kg
47260734 mm²紫色4.9 mm38.400 kg0.045 kg
4726073K4 mm²紫色大纸箱4.9 mm38.400 kg0.045 kg
47260746 mm²紫色5.5 mm57.600 kg0.065 kg
4726074K6 mm²紫色大纸箱5.5 mm57.600 kg0.065 kg
472607510 mm²紫色7.1 mm96.000 kg0.110 kg
472607616 mm²紫色8.4 mm153.600 kg0.170 kg
472607725 mm²紫色10.6 mm240.000 kg0.290 kg
472607835 mm²紫色12.1 mm336.000 kg0.400 kg
472607950 mm²紫色14.4 mm480.000 kg0.550 kg
47260811.5 mm²粉红色3.5 mm14.400 kg0.020 kg
4726081K1.5 mm²粉红色大纸箱3.5 mm14.400 kg0.020 kg
47260822.5 mm²粉红色4.3 mm24.000 kg0.032 kg
4726082K2.5 mm²粉红色大纸箱4.3 mm24.000 kg0.030 kg
47260834 mm²粉红色4.9 mm38.400 kg0.045 kg
4726083K4 mm²粉红色大纸箱4.9 mm38.400 kg0.045 kg
47260846 mm²粉红色5.5 mm57.600 kg0.065 kg
4726084K6 mm²粉红色大纸箱5.5 mm57.600 kg0.065 kg
472608510 mm²粉红色7.1 mm96.000 kg0.110 kg
472608616 mm²粉红色8.4 mm153.600 kg0.170 kg
472608725 mm²粉红色10.6 mm240.000 kg0.290 kg
472608835 mm²粉红色12.1 mm336.000 kg0.380 kg
472608950 mm²粉红色14.4 mm480.000 kg0.530 kg
47260911.5 mm²橙色3.5 mm14.400 kg0.020 kg
4726091K1.5 mm²橙色大纸箱3.5 mm14.400 kg0.020 kg
4726091S1.5 mm²橙色盘装3.5 mm14.400 kg0.020 kg
47260922.5 mm²橙色4.3 mm24.000 kg0.030 kg
4726092K2.5 mm²橙色大纸箱4.3 mm24.000 kg0.030 kg
4726092S2.5 mm²橙色盘装4.3 mm24.000 kg0.032 kg
47260934 mm²橙色4.9 mm38.400 kg0.045 kg
4726093K4 mm²橙色大纸箱4.9 mm38.400 kg0.045 kg
47260946 mm²橙色5.5 mm57.600 kg0.065 kg
4726094K6 mm²橙色大纸箱5.5 mm57.600 kg0.065 kg
472609510 mm²橙色7.1 mm96.000 kg0.110 kg
472609616 mm²橙色8.4 mm153.600 kg0.170 kg
472609725 mm²橙色10.6 mm240.000 kg0.290 kg
472609835 mm²橙色12.1 mm336.000 kg0.400 kg
472609950 mm²橙色14.4 mm480.000 kg0.550 kg
47261111.5 mm²黄色3.5 mm14.400 kg0.020 kg
4726111K1.5 mm²黄色大纸箱3.5 mm14.400 kg0.020 kg
4726111S1.5 mm²黄色盘装3.5 mm14.400 kg0.020 kg
47261122.5 mm²黄色4.3 mm24.000 kg0.030 kg
4726112K2.5 mm²黄色大纸箱4.3 mm24.000 kg0.032 kg
4726112S2.5 mm²黄色盘装4.3 mm24.000 kg0.032 kg
47261134 mm²黄色4.9 mm38.400 kg0.045 kg
4726113K4 mm²黄色大纸箱4.9 mm38.400 kg0.045 kg
47261146 mm²黄色5.5 mm57.600 kg0.065 kg
4726114K6 mm²黄色大纸箱5.5 mm57.600 kg0.065 kg
472611510 mm²黄色7.1 mm96.000 kg0.110 kg
472611616 mm²黄色8.4 mm153.600 kg0.170 kg
472611725 mm²黄色10.6 mm240.000 kg0.290 kg
472611835 mm²黄色12.1 mm336.000 kg0.400 kg
472611950 mm²黄色14.4 mm480.000 kg0.550 kg
47261211.5 mm²绿色3.5 mm14.400 kg0.020 kg
4726121K1.5 mm²绿色大纸箱3.5 mm14.400 kg0.020 kg
4726121S1.5 mm²绿色盘装3.5 mm14.400 kg0.020 kg
47261222.5 mm²绿色4.3 mm24.000 kg0.030 kg
4726122K2.5 mm²绿色大纸箱4.3 mm24.000 kg0.032 kg
4726122S2.5 mm²绿色盘装4.3 mm24.000 kg0.032 kg
47261234 mm²绿色4.9 mm38.400 kg0.045 kg
4726123K4 mm²绿色大纸箱4.9 mm38.400 kg0.045 kg
47261246 mm²绿色5.5 mm57.600 kg0.065 kg
4726124K6 mm²绿色大纸箱5.5 mm57.600 kg0.065 kg
472612510 mm²绿色7.1 mm96.000 kg0.110 kg
472612616 mm²绿色8.4 mm153.600 kg0.170 kg
472612725 mm²绿色10.6 mm240.000 kg0.290 kg
472612835 mm²绿色12.1 mm336.000 kg0.400 kg
472612950 mm²绿色14.4 mm480.000 kg0.550 kg
47261411.5 mm²深蓝色3.5 mm14.400 kg0.020 kg
4726141K1.5 mm²深蓝色大纸箱3.5 mm14.400 kg0.020 kg
4726141S1.5 mm²深蓝色盘装3.5 mm14.400 kg0.020 kg
47261422.5 mm²深蓝色4.3 mm24.000 kg0.030 kg
4726142K2.5 mm²深蓝色大纸箱4.3 mm24.000 kg0.030 kg
4726142S2.5 mm²深蓝色盘装4.3 mm24.000 kg0.032 kg
47261434 mm²深蓝色4.9 mm38.400 kg0.045 kg
4726143K4 mm²深蓝色大纸箱4.9 mm38.400 kg0.045 kg
47261446 mm²深蓝色5.5 mm57.600 kg0.065 kg
4726144K6 mm²深蓝色大纸箱5.5 mm57.600 kg0.065 kg
472614510 mm²深蓝色7.1 mm96.000 kg0.110 kg
472614616 mm²深蓝色8.4 mm153.600 kg0.170 kg
472614725 mm²深蓝色10.6 mm240.000 kg0.290 kg
472614835 mm²深蓝色12.1 mm336.000 kg0.400 kg
472614950 mm²深蓝色14.4 mm480.000 kg0.550 kg
4726261K1.5 mm²蓝色-白色大纸箱3.5 mm14.400 kg0.020 kg
4726262K2.5 mm²蓝色-白色大纸箱4.3 mm24.000 kg0.013 kg
472700170 mm²绿色-黄色16.6 mm672.000 kg0.750 kg
472700295 mm²绿色-黄色18.8 mm912.000 kg1.000 kg
472701170 mm²黑色16.6 mm672.000 kg0.780 kg
472701295 mm²黑色18.8 mm912.000 kg1.055 kg
472702170 mm²蓝色16.6 mm672.000 kg0.750 kg
472702295 mm²蓝色18.8 mm912.000 kg1.000 kg
472703170 mm²褐色16.6 mm672.000 kg0.750 kg
472703295 mm²褐色18.8 mm912.000 kg1.000 kg
472704170 mm²红色16.6 mm672.000 kg0.750 kg
472704295 mm²红色18.8 mm912.000 kg1.000 kg
472705170 mm²白色16.6 mm672.000 kg0.750 kg
472705295 mm²白色18.8 mm912.000 kg1.000 kg
472706170 mm²灰色16.6 mm672.000 kg0.750 kg
472706295 mm²灰色18.8 mm912.000 kg1.000 kg
472707170 mm²紫色16.6 mm672.000 kg0.750 kg
472707295 mm²紫色18.8 mm912.000 kg1.000 kg
472708170 mm²粉红色16.6 mm672.000 kg0.780 kg
472708295 mm²粉红色18.8 mm912.000 kg1.055 kg
472709170 mm²橙色16.6 mm672.000 kg0.750 kg
472709295 mm²橙色18.8 mm912.000 kg1.000 kg
472711170 mm²黄色16.6 mm672.000 kg0.750 kg
472711295 mm²黄色18.8 mm912.000 kg1.000 kg
472712170 mm²绿色16.6 mm672.000 kg0.750 kg
472712295 mm²绿色18.8 mm912.000 kg1.000 kg
472714170 mm²深蓝色16.6 mm672.000 kg0.750 kg
472714295 mm²深蓝色18.8 mm912.000 kg1.000 kg
