首页 > 供应产品 > 缆普LAPP 电缆和电线 单芯线MULTI-STANDARD SC 2.1 1X4 GNYE
缆普LAPP 电缆和电线 单芯线MULTI-STANDARD SC 2.1 1X4 GNYE
MULTI-STANDARD SC 2.1 1X4 GNYE 单芯线; 1X4; 绿色-黄色; 卷; U0/U: 450 / 750 V; PVC; HAR 认证; UL 列名; 固定敷设
型号名称: 缆普LAPP 电缆和电线 单芯线MULTI-STANDARD SC 2.1 1X4 GNYE
浏览次数: 25
产品品牌: 缆普LAPP
产品标签: 缆普 LAPP 电缆和电线 单芯线 4160600
产品单价: 面议
最小起订量:
供货总量: 电询
发货期限: 自买家付款之日起 3 天内发货
有效期至: 2023-12-19
最后更新: 2022-12-19 16:08

详细信息

优势

  • 根据统一欧洲规格 H07V-K 制造,带 ◁HAR▷ 安全和质量检测标志(不适用于尺寸 0.5 / 0.75 / 1.0 / 16 mm²,绿色和黄色单色以及除绿黄色之外的双色)。

  • 根据技术数据进行的UL认证使产品能够在北美市场上使用。

  • 获得多项认证的产品实现了通用性,减少零件种类,从而确保物流节省。

  • 设计紧凑,易于加工。

  • 可多样性地用于各种应用和环境。

  • 根据欧盟指令305/2011(BauPVO/CPR)对火灾行为进行分类,物料选型详见www.lappkabel.de/CPR。

  • 可提供不同芯线绝缘层颜色的款型。

  • 可提供卷装或一次性大包装箱款型。根据颜色和横截面,可使用大纸板箱,通常导线横截面最大为6 mm²。

应用

  • 用于机器内部电路的布线。

  • 适用于控制柜内的布线。

  • 用于固定和受保护的敷设。

  • 可在干燥或潮湿的空间中使用。

  • 可在最低 -40 °C 的温度下使用。

技术特性

基本信息

产品类型

单芯线

重量

0.049 kg

铜号

38.400 kg

铜重 (lb)

258.000 lb

产品设计

电缆尺寸

1X4

认证标准

EAC certified


EAC 认证编号

ЕАЭС N RU Д-DE.АЮ64.В.00130/20, ЕАЭС N RU Д-DE.АЮ64.В.00142/20

产品系列列表

所有物料号来自 MULTI-STANDARD SC 2.1

物料编号导体额定横截面 (mm2)单芯线颜色单芯线包装类型芯线额定直径铜号重量
41601000.5 mm²绿色-黄色2.5 mm4.800 kg0.010 kg
41601010.5 mm²黑色2.5 mm4.800 kg0.010 kg
4160101K0.5 mm²黑色大纸箱2.5 mm4.800 kg0.010 kg
41601020.5 mm²蓝色2.5 mm4.800 kg0.011 kg
4160102K0.5 mm²蓝色大纸箱2.5 mm4.800 kg0.010 kg
41601030.5 mm²褐色2.5 mm4.800 kg0.011 kg
4160103K0.5 mm²褐色大纸箱2.5 mm4.800 kg0.010 kg
41601040.5 mm²红色2.5 mm4.800 kg0.010 kg
4160104K0.5 mm²红色大纸箱2.5 mm4.800 kg0.010 kg
41601050.5 mm²白色2.5 mm4.800 kg0.011 kg
4160105K0.5 mm²白色大纸箱2.5 mm4.800 kg0.010 kg
41601060.5 mm²灰色2.5 mm4.800 kg0.011 kg
4160106K0.5 mm²灰色大纸箱2.5 mm4.800 kg0.010 kg
41601070.5 mm²紫色2.5 mm4.800 kg0.010 kg
4160107K0.5 mm²紫色大纸箱2.5 mm4.800 kg0.010 kg
41601080.5 mm²粉红色2.5 mm4.800 kg0.010 kg
41601090.5 mm²橙色2.5 mm4.800 kg0.010 kg
4160109K0.5 mm²橙色大纸箱2.5 mm4.800 kg0.010 kg
41601100.5 mm²黄色2.5 mm4.800 kg0.010 kg
41601110.5 mm²绿色2.5 mm4.800 kg0.010 kg
41601140.5 mm²深蓝色2.5 mm4.800 kg0.011 kg
4160114K0.5 mm²深蓝色大纸箱2.5 mm4.800 kg0.010 kg
41601260.5 mm²蓝色-白色2.5 mm4.800 kg0.010 kg
41601440.5 mm²白色-蓝色2.5 mm4.800 kg0.010 kg
4160144K0.5 mm²白色-蓝色大纸箱2.5 mm4.800 kg0.010 kg
41602000.75 mm²绿色-黄色2.7 mm7.200 kg0.014 kg
4160200K0.75 mm²绿色-黄色大纸箱2.7 mm7.200 kg0.012 kg
41602010.75 mm²黑色2.7 mm7.200 kg0.014 kg
4160201K0.75 mm²黑色大纸箱2.7 mm7.200 kg0.012 kg
41602020.75 mm²蓝色2.7 mm7.200 kg0.014 kg
4160202K0.75 mm²蓝色大纸箱2.7 mm7.200 kg0.012 kg
41602030.75 mm²褐色2.7 mm7.200 kg0.014 kg
4160203K0.75 mm²褐色大纸箱2.7 mm7.200 kg0.012 kg
41602040.75 mm²红色2.7 mm7.200 kg0.014 kg
41602050.75 mm²白色2.7 mm7.200 kg0.014 kg
4160205K0.75 mm²白色大纸箱2.7 mm7.200 kg0.012 kg
41602060.75 mm²灰色2.7 mm7.200 kg0.014 kg
4160206K0.75 mm²灰色大纸箱2.7 mm7.200 kg0.012 kg
41602070.75 mm²紫色2.7 mm7.200 kg0.014 kg
4160207K0.75 mm²紫色大纸箱2.7 mm7.200 kg0.012 kg
41602080.75 mm²粉红色2.7 mm7.200 kg0.014 kg
41602090.75 mm²橙色2.7 mm7.200 kg0.014 kg
4160209K0.75 mm²橙色大纸箱2.7 mm7.200 kg0.012 kg
41602100.75 mm²黄色2.7 mm7.200 kg0.014 kg
41602110.75 mm²绿色2.7 mm7.200 kg0.014 kg
41602140.75 mm²深蓝色2.7 mm7.200 kg0.014 kg
4160214K0.75 mm²深蓝色大纸箱2.7 mm7.200 kg0.012 kg
41602260.75 mm²蓝色-白色2.7 mm7.200 kg0.014 kg
4160226K0.75 mm²蓝色-白色大纸箱2.7 mm7.200 kg0.012 kg
41602440.75 mm²白色-蓝色2.7 mm7.200 kg0.014 kg
4160244K0.75 mm²白色-蓝色大纸箱2.7 mm7.200 kg0.012 kg
41603001 mm²绿色-黄色2.9 mm9.600 kg0.017 kg
4160300K1 mm²绿色-黄色大纸箱2.9 mm9.600 kg0.016 kg
41603011 mm²黑色2.9 mm9.600 kg0.016 kg
4160301K1 mm²黑色大纸箱2.9 mm9.600 kg0.016 kg
41603021 mm²蓝色2.9 mm9.600 kg0.016 kg
4160302K1 mm²蓝色大纸箱2.9 mm9.600 kg0.016 kg
41603031 mm²褐色2.9 mm9.600 kg0.016 kg
4160303K1 mm²褐色大纸箱2.9 mm9.600 kg0.016 kg
41603041 mm²红色2.9 mm9.600 kg0.016 kg
4160304K1 mm²红色大纸箱2.9 mm9.600 kg0.016 kg
41603051 mm²白色2.9 mm9.600 kg0.016 kg
4160305K1 mm²白色大纸箱2.9 mm9.600 kg0.016 kg
41603061 mm²灰色2.9 mm9.600 kg0.016 kg
4160306K1 mm²灰色大纸箱2.9 mm9.600 kg0.016 kg
41603071 mm²紫色2.9 mm9.600 kg0.016 kg
41603081 mm²粉红色2.9 mm9.600 kg0.016 kg
41603091 mm²橙色2.9 mm9.600 kg0.016 kg
4160309K1 mm²橙色大纸箱2.9 mm9.600 kg0.016 kg
41603101 mm²黄色2.9 mm9.600 kg0.017 kg
4160310K1 mm²黄色大纸箱2.9 mm9.600 kg0.016 kg
41603111 mm²绿色2.9 mm9.600 kg0.016 kg
41603141 mm²深蓝色2.9 mm9.600 kg0.016 kg
4160314K1 mm²深蓝色大纸箱2.9 mm9.600 kg0.016 kg
41603261 mm²蓝色-白色2.9 mm9.600 kg0.016 kg
4160326K1 mm²蓝色-白色大纸箱2.9 mm9.600 kg0.016 kg
41603441 mm²白色-蓝色2.9 mm9.600 kg0.016 kg
4160344K1 mm²白色-蓝色大纸箱2.9 mm9.600 kg0.016 kg
41604001.5 mm²绿色-黄色3.1 mm14.400 kg0.020 kg
4160400K1.5 mm²绿色-黄色大纸箱3.1 mm14.400 kg0.020 kg
41604011.5 mm²黑色3.1 mm14.400 kg0.022 kg
4160401K1.5 mm²黑色大纸箱3.1 mm14.400 kg0.020 kg
41604021.5 mm²蓝色3.1 mm14.400 kg0.022 kg
4160402K1.5 mm²蓝色大纸箱3.1 mm14.400 kg0.020 kg
41604031.5 mm²褐色3.1 mm14.400 kg0.020 kg
4160403K1.5 mm²褐色大纸箱3.1 mm14.400 kg0.020 kg
41604041.5 mm²红色3.1 mm14.400 kg0.020 kg
4160404K1.5 mm²红色大纸箱3.1 mm14.400 kg0.020 kg
41604051.5 mm²白色3.1 mm14.400 kg0.022 kg
4160405K1.5 mm²白色大纸箱3.1 mm14.400 kg0.020 kg
41604061.5 mm²灰色3.1 mm14.400 kg0.020 kg
4160406K1.5 mm²灰色大纸箱3.1 mm14.400 kg0.020 kg
41604071.5 mm²紫色3.1 mm14.400 kg0.020 kg
41604081.5 mm²粉红色3.1 mm14.400 kg0.020 kg
41604091.5 mm²橙色3.1 mm14.400 kg0.020 kg
4160409K1.5 mm²橙色大纸箱3.1 mm14.400 kg0.020 kg
41604101.5 mm²黄色3.1 mm14.400 kg0.020 kg
4160410K1.5 mm²黄色大纸箱3.1 mm14.400 kg0.020 kg
41604111.5 mm²绿色3.1 mm14.400 kg0.020 kg
41604141.5 mm²深蓝色3.1 mm14.400 kg0.022 kg
4160414K1.5 mm²深蓝色大纸箱3.1 mm14.400 kg0.020 kg
41604261.5 mm²蓝色-白色3.1 mm14.400 kg0.022 kg
4160426K1.5 mm²蓝色-白色大纸箱3.1 mm14.400 kg0.020 kg
41604441.5 mm²白色-蓝色3.1 mm14.400 kg0.020 kg
4160444K1.5 mm²白色-蓝色大纸箱3.1 mm14.400 kg0.020 kg
41604571.5 mm²白色3.1 mm14.400 kg0.020 kg
41605002.5 mm²绿色-黄色3.6 mm24.000 kg0.031 kg
4160500K2.5 mm²绿色-黄色大纸箱3.6 mm24.000 kg0.032 kg
41605012.5 mm²黑色3.6 mm24.000 kg0.037 kg
4160501K2.5 mm²黑色大纸箱3.6 mm24.000 kg0.032 kg
41605022.5 mm²蓝色3.6 mm24.000 kg0.031 kg
4160502K2.5 mm²蓝色大纸箱3.6 mm24.000 kg0.032 kg
41605032.5 mm²褐色3.6 mm24.000 kg0.037 kg
4160503K2.5 mm²褐色大纸箱3.6 mm24.000 kg0.037 kg
41605042.5 mm²红色3.6 mm24.000 kg0.031 kg
4160504K2.5 mm²红色大纸箱3.6 mm24.000 kg0.037 kg
41605052.5 mm²白色3.6 mm24.000 kg0.037 kg
4160505K2.5 mm²白色大纸箱3.6 mm24.000 kg0.031 kg
41605062.5 mm²灰色3.6 mm24.000 kg0.037 kg
4160506K2.5 mm²灰色大纸箱3.6 mm24.000 kg0.037 kg
41605072.5 mm²紫色3.6 mm24.000 kg0.037 kg
41605092.5 mm²橙色3.6 mm24.000 kg0.037 kg
4160509K2.5 mm²橙色大纸箱3.6 mm24.000 kg0.037 kg
41605102.5 mm²黄色3.6 mm24.000 kg0.037 kg
4160510K2.5 mm²黄色大纸箱3.6 mm24.000 kg0.037 kg
41605112.5 mm²绿色3.6 mm24.000 kg0.031 kg
41605142.5 mm²深蓝色3.6 mm24.000 kg0.031 kg
4160514K2.5 mm²深蓝色大纸箱3.6 mm24.000 kg0.037 kg
41605262.5 mm²蓝色-白色3.6 mm24.000 kg0.037 kg
41605442.5 mm²白色-蓝色3.6 mm24.000 kg0.031 kg
4160544K2.5 mm²白色-蓝色大纸箱3.6 mm24.000 kg0.037 kg
41606004 mm²绿色-黄色4.3 mm38.400 kg0.049 kg
4160600K4 mm²绿色-黄色大纸箱4.3 mm38.400 kg0.045 kg
41606014 mm²黑色4.3 mm38.400 kg0.049 kg
4160601K4 mm²黑色大纸箱4.3 mm38.400 kg0.045 kg
41606024 mm²蓝色4.3 mm38.400 kg0.045 kg
4160602K4 mm²蓝色大纸箱4.3 mm38.400 kg0.045 kg
41606034 mm²褐色4.3 mm38.400 kg0.049 kg
4160603K4 mm²褐色大纸箱4.3 mm38.400 kg0.044 kg
41606044 mm²红色4.3 mm38.400 kg0.049 kg
4160604K4 mm²红色大纸箱4.3 mm38.400 kg0.044 kg
41606054 mm²白色4.3 mm38.400 kg0.049 kg
41606064 mm²灰色4.3 mm38.400 kg0.049 kg
41606074 mm²紫色4.3 mm38.400 kg0.049 kg
41606094 mm²橙色4.3 mm38.400 kg0.049 kg
4160609K4 mm²橙色大纸箱4.3 mm38.400 kg0.044 kg
41606104 mm²黄色4.3 mm38.400 kg0.044 kg
4160610K4 mm²黄色大纸箱4.3 mm38.400 kg0.044 kg
41606114 mm²绿色4.3 mm38.400 kg0.044 kg
41606144 mm²深蓝色4.3 mm38.400 kg0.049 kg
4160614K4 mm²深蓝色大纸箱4.3 mm38.400 kg0.044 kg
41606264 mm²蓝色-白色4.3 mm38.400 kg0.045 kg
41606444 mm²白色-蓝色4.3 mm38.400 kg0.045 kg
41607006 mm²绿色-黄色4.8 mm57.600 kg0.068 kg
4160700K6 mm²绿色-黄色大纸箱4.8 mm57.600 kg0.063 kg
41607016 mm²黑色4.8 mm57.600 kg0.067 kg
4160701K6 mm²黑色大纸箱4.8 mm57.600 kg0.063 kg
41607026 mm²蓝色4.8 mm57.600 kg0.068 kg
4160702K6 mm²蓝色大纸箱4.8 mm57.600 kg0.063 kg
41607036 mm²褐色4.8 mm57.600 kg0.063 kg
41607046 mm²红色4.8 mm57.600 kg0.068 kg
4160704K6 mm²红色大纸箱4.8 mm57.600 kg0.063 kg
41607056 mm²白色4.8 mm57.600 kg0.063 kg
41607066 mm²灰色4.8 mm57.600 kg0.063 kg
4160706K6 mm²灰色大纸箱4.8 mm57.600 kg0.063 kg
41607076 mm²紫色4.8 mm57.600 kg0.063 kg
41607096 mm²橙色4.8 mm57.600 kg0.067 kg
4160709K6 mm²橙色大纸箱4.8 mm57.600 kg0.063 kg
41607106 mm²黄色4.8 mm57.600 kg0.063 kg
41607116 mm²绿色4.8 mm57.600 kg0.063 kg
41607146 mm²深蓝色4.8 mm57.600 kg0.063 kg
4160714K6 mm²深蓝色大纸箱4.8 mm57.600 kg0.063 kg
41607266 mm²蓝色-白色4.8 mm57.600 kg0.063 kg
41607446 mm²白色-蓝色4.8 mm57.600 kg0.063 kg
416080010 mm²绿色-黄色6.5 mm96.000 kg0.116 kg
416080110 mm²黑色6.5 mm96.000 kg0.120 kg
416080210 mm²蓝色6.5 mm96.000 kg0.120 kg
416080310 mm²褐色6.5 mm96.000 kg0.120 kg
416080410 mm²红色6.5 mm96.000 kg0.120 kg
416080510 mm²白色6.5 mm96.000 kg0.120 kg
416080610 mm²灰色6.5 mm96.000 kg0.120 kg
416080910 mm²橙色6.5 mm96.000 kg0.120 kg
416081010 mm²黄色6.5 mm96.000 kg0.120 kg
416081110 mm²绿色6.5 mm96.000 kg0.120 kg
416081410 mm²深蓝色6.5 mm96.000 kg0.120 kg
416082610 mm²蓝色-白色6.5 mm96.000 kg0.120 kg
416084410 mm²白色-蓝色6.5 mm96.000 kg0.120 kg
416090016 mm²绿色-黄色8.6 mm153.600 kg0.185 kg
416090116 mm²黑色8.6 mm153.600 kg0.185 kg
416090216 mm²蓝色8.6 mm153.600 kg0.185 kg
416090316 mm²褐色8.6 mm153.600 kg0.185 kg
416090416 mm²红色8.6 mm153.600 kg0.185 kg
416090516 mm²白色8.6 mm153.600 kg0.185 kg
416090616 mm²灰色8.6 mm153.600 kg0.185 kg
416090916 mm²橙色8.6 mm153.600 kg0.185 kg
416091016 mm²黄色8.6 mm153.600 kg0.185 kg
416091116 mm²绿色8.6 mm153.600 kg0.185 kg
416091416 mm²深蓝色8.6 mm153.600 kg0.185 kg
416100025 mm²绿色-黄色9.8 mm240.000 kg0.260 kg
416100125 mm²黑色9.8 mm240.000 kg0.260 kg
416100225 mm²蓝色9.8 mm240.000 kg0.260 kg
416100325 mm²褐色9.8 mm240.000 kg0.260 kg
416100425 mm²红色9.8 mm240.000 kg0.260 kg
416100525 mm²白色9.8 mm240.000 kg0.260 kg
416100625 mm²灰色9.8 mm240.000 kg0.261 kg
416100925 mm²橙色9.8 mm240.000 kg0.260 kg
416101025 mm²黄色9.8 mm240.000 kg0.260 kg
416101125 mm²绿色9.8 mm240.000 kg0.260 kg
416110035 mm²绿色-黄色11.3 mm336.000 kg0.360 kg
416110135 mm²黑色11.3 mm336.000 kg0.360 kg
416110235 mm²蓝色11.3 mm336.000 kg0.360 kg
416110435 mm²红色11.3 mm336.000 kg0.360 kg
416110535 mm²白色11.3 mm336.000 kg0.360 kg
416110635 mm²灰色11.3 mm336.000 kg0.360 kg
416111135 mm²绿色11.3 mm336.000 kg0.360 kg
416120050 mm²绿色-黄色13.5 mm480.000 kg0.535 kg
416120150 mm²黑色13.5 mm480.000 kg0.535 kg
416120250 mm²蓝色13.5 mm480.000 kg0.535 kg
416121150 mm²绿色13.5 mm480.000 kg0.535 kg
416130070 mm²绿色-黄色15.6 mm672.000 kg0.735 kg
416130170 mm²黑色15.6 mm672.000 kg0.735 kg
416140095 mm²绿色-黄色17.8 mm912.000 kg0.930 kg
416140195 mm²黑色17.8 mm912.000 kg0.930 kg
416140295 mm²蓝色17.8 mm912.000 kg0.930 kg
4161500125 mm²绿色-黄色19.4 mm1152.000 kg1.160 kg
4161501125 mm²黑色19.4 mm1152.000 kg1.160 kg
4161502125 mm²蓝色19.4 mm1152.000 kg1.285 kg
